FAIL
Cell placement error
- Pack number
- FLX BAT 0002
- Configuration
- 20S3P
- Expected cells
- 60
- Detected cells
- 60
- AI confidence
- 85%
AI analysis
The pack has the correct total of 60 cells in a 10x6 grid, and most rows show the expected checkerboard alternation between left (columns 1-3) and right (columns 4-6) groups. However, row 6's right-hand group deviates from the alternating pattern seen in the reference image, indicating a likely orientation error affecting that group of 3 cells. Operator should visually re-check row 6, columns 4-6, and reorient if needed to match the series wiring pattern.
Decision: AI inspection reported a placement error.
Detected issues (1)
- HIGHOrientation anomalyIn row 6 from the top, the right-hand parallel group (columns 4-6) shows flat plain silver disc terminals (negative), whereas in the reference image the same row's right group shows ringed button terminals (positive). This breaks the expected alternating checkerboard pattern between rows and suggests this group of 3 cells was inserted facing the wrong way relative to the intended series pattern.
