PASS
Cell placement verified
- Pack number
- FLXBAT0003
- Configuration
- 20S3P
- Expected cells
- 60
- Detected cells
- 60
- AI confidence
- 96%
AI analysis
All 10 rows x 6 columns are filled with 60 cells total, no missing or extra cells. Each row shows the expected checkerboard pattern: columns 1-3 form one group and columns 4-6 form another, with all three cells within each group consistently facing the same direction (either all flat discs or all raised buttons), and the pattern alternates row to row as expected for series wiring.
Whole pack, 10 rows x 6 columns
Decision: Detected 60/60 cells with 96% confidence and no structural issues.
Inspection images
Original image

AI inspection
No cell-level coordinates could be determined reliably, so no boxes are drawn. Whole pack, 10 rows x 6 columns
Was this verdict right?
Audit trail
| Inspector | Line Administrator |
|---|---|
| Inspected at | 21 Sept 2026, 19:41 |
| Configuration | 20S3P (20S ร 3P) |
| Reference configuration version | v3 โ configuration has since been revised to v5 |
| Learning calibration used | none yet (defaults) |
| AI provider | anthropic |
| AI model | claude-sonnet-5 |
| Decision rule applied | Detected 60/60 cells with 96% confidence and no structural issues. |
| Inspection duration | 4.4s |
| Uploaded image | inspections/2026/09/917cf1ed-e90a-4b1b-aa78-564a9199a7a2.png |
| Record type | Production |
