FAIL
Cell placement error
- Pack number
- FLXBATPRO
- Configuration
- 20S3P
- Expected cells
- 60
- Detected cells
- 59
- AI confidence
- 95%
AI analysis
All other 59 positions are filled and the checkerboard orientation pattern (left group vs right group alternating, and flipping row to row) is consistent with the expected 20S3P layout, matching the reference. However, row 4 column 1 is an empty holder with no cell installed, leaving that parallel group with only 2 of 3 cells - this must be corrected before the pack ships.
Decision: Cell count mismatch: detected 59, expected 60.
Detected issues (2)
- HIGHMissing cellPosition row 4, column 1 (left group of that row) is an empty holder - no cell present, showing the bare plastic holder shape instead of a cell terminal.
- HIGHMissing cellDetected 59 cells but the selected configuration expects 60 (-1).
Inspection images
Original image
AI inspection
Audit trail
| Inspector | Line Administrator |
|---|---|
| Inspected at | 21 Sept 2026, 19:53 |
| Configuration | 20S3P (20S × 3P) |
| Reference configuration version | v3 |
| AI provider | anthropic |
| AI model | claude-sonnet-5 |
| Decision rule applied | Cell count mismatch: detected 59, expected 60. |
| Inspection duration | 7.2s |
| Uploaded image | inspections/2026/09/50cd0d3b-90c3-4eab-b380-df8ed7b0c271.png |
| Record type | Production |
