FAIL
Cell placement error
- Pack number
- FLX-BAT-0001
- Configuration
- 20S3P
- Expected cells
- 60
- Detected cells
- 60
- AI confidence
- 90%
AI analysis
Overall count is correct at 60 cells arranged in 10 rows x 6 columns matching 20S3P. However, comparing row-by-row orientation flips against the reference image, rows 5 and 6 (right-hand groups, columns 4-6) both show plain silver disc faces instead of alternating with ringed button faces as seen in the reference - this breaks the expected checkerboard pattern. Recommend operator visually re-verify these two groups against the reference to confirm correct series polarity wiring will still be achieved before shipping.
Decision: AI inspection reported a placement error.
Detected issues (2)
- MEDIUMOrientation anomalyIn row 6 (counting from top), the right-hand group of 3 (columns 4-6) shows all three cells as plain silver discs (negative), but in the reference image the same row's right group shows ringed button cells (positive). Additionally within the inspected image, row 6 right group appears uniform, but comparing to row 5 right group directly above it (also plain discs) breaks the expected row-to-row flip pattern seen in the reference.
- LOWOrientation anomalyRow 5, right group (columns 4-6): all three cells show plain silver discs, matching row 6 right group below rather than alternating. In the reference image, rows alternate group orientation row-by-row; here rows 5 and 6 right-side groups both show the same facing, indicating a deviation from the expected checkerboard/row-flip pattern.
