FLX-BAT-0001

Expected

60

Detected

60

Confidence

90%

Overall count is correct at 60 cells arranged in 10 rows x 6 columns matching 20S3P. However, comparing row-by-row orientation flips against the reference image, rows 5 and 6 (right-hand groups, columns 4-6) both show plain silver disc faces instead of alternating with ringed button faces as seen in the reference - this breaks the expected checkerboard pattern. Recommend operator visually re-verify these two groups against the reference to confirm correct series polarity wiring will still be achieved before shipping.

Expected

60

Detected

60

Confidence

65%

The pack contains 60 visible cells arranged in a 10x6 grid, matching the expected 20S3P count and layout, with all holder positions filled and no obviously missing or extra cells. There is a visible difference in cell cap coloration/orientation pattern between the left three columns and right three columns compared to the reference image, which could indicate mixed cell types/batches within a parallel group or could simply be a lighting/glare artifact - manual visual confirmation recommended before final pass.

Expected

60

Detected

60

Confidence

75%

The pack shows a complete 6x10 grid of 60 cylindrical cells with no missing or empty holder positions, matching the expected 20S3P count and physical layout. The left/right 3-cell grouping pattern generally alternates in texture as in the reference, though a few rows show minor mixing of flat vs. ribbed cell tops within a parallel group, which could indicate a cell placed with inconsistent orientation. No structural placement errors (missing, extra, or displaced cells) were found, so the pack passes on layout/count, but the orientation detail is worth a quick visual re-check on the line.
